Rohde & Schwarz RTH-24F Handheld Oscilloscope Bundle, 4 Ch, 200MHz, LAN, w/Carrying Case, RTH Series

Rohde & Schwarz RTH Series - RTH-24F Handheld Oscilloscope Bundle

The R&S RTH-24F is a preconfigured R&S Scope Rider handheld oscilloscope package that combines the proven portability and safety of the RTH platform with enhanced bandwidth performance for demanding signal analysis applications. Designed for engineers working with industrial electronics, embedded systems, and field service diagnostics, it delivers isolated inputs, high-speed sampling, rugged IP51 construction, and the flexibility of multiple integrated measurement tools. Its handheld design and CAT IV safety rating make it well suited for troubleshooting in challenging environments while maintaining laboratory-grade measurement quality.

Key Facts (RTH1004):

• Bandwidth: 200 MHz

• Sample rate: up to 5 Gsample/s

• Memory depth: 2 Mpts segmented memory

• ADC resolution: 10-bit

• Isolated channels (CAT IV 600 V (RMS) / CAT III 1000 V (RMS)

• 50 000 waveforms per second

• 37 automatic measurement functions

• More than 4 hours of battery power

• 7" Capacitive touch display

• Unmatched connectivity: USB, Ethernet and wireless LAN

• Rugged, dust and water resistant housing

Bundle Includes:

• RTH1004 Handheld 4 Channel Oscilloscope

• RTH-B242 200 MHz bandwidth

• HA-Z302 Power Supply for Vehicles

• HA-Z303 External Battery Charger

• RT-ZI10 Passive Probe 500 MHz

• RT-ZA21 Extension for RT-ZI10

• RTH-K15 History & segmented memory

• RTH-K200 Wireless LAN except US/Canada/EU

• RTH-K201 Remote Control

• RTH-Z4 Carrying Case

Superior performance

Lab performance in a rugged, portable design

When debugging embedded devices in the lab or analyzing complex problems at the customer site, the R&S Scope Rider offers the performance and capabilities of a lab oscilloscope as well as the form factor and ruggedness of a battery-operated handheld device.

Eight instruments in one portable design

Debugging power in your hands

With the power of eight instruments, R&S Scope Rider provides the capabilities and the flexibility needed to debug all kinds of electronic systems in the lab and in the field.

In The Box:

• R&S RTH1004 Handheld Oscilloscope

• 500 MHz, 10:1, 600 V CAT IV voltage probe for each input channel,

• Power supply with plugs for EU, GB and US

• Battery pack

• Soft handle
