Tektronix Spring 2020 Promotion Event

Get big upgrades, industry-leading accuracy and performance, with all-in-one oscilloscopes and industry-standard source measurement units.


3 Series MDO Mixed-Domain Oscilloscope

The award-winning 3 Series MDO gets even better with industry first features and big savings.

  • 11.6" HD (1920x1080) touchscreen
  • 2 or 4 analog channels
  • 16 optional digital channels
  • 5-in-1 instrument (Scope, Spectrum analyzer, Digital Voltmeter, Frequency counter, AFG)
  • 5 Gs/s maximum sampling rate, and 10M record length
  • Optional built-in spectrum analyzer in 1 GHz or 3 GHz versions
  • See the 3 Series MDO family HERE.

Limited-Time Offer
Get 16 FREE digital channels (SUP3-MSO), and 75% OFF our software bundle SUP3-BND (which includes 3-SRAERO, 3 SR-AUDIO, 3-SRAUTO, 3-SRCOMP, 3-SREMBD, 3-PWR, 3-SRUSB2)

4 Series MSO Mixed-Signal Oscilloscope

Flexibility. Upgradeability. Affordability. 4 Series MSO delivers all of the above, with big savings.

  • 13.3" HD (1920x1080) touchscreen
  • Up to 6 FlexChannel® inputs for analog or digital channels
  • 12-bit vertical resolution
  • 6.25 GS/s Sampling Rate on all analog/digital channels
  • 31.25 Mpoints Record Length (standard) or 62.5 Mpoints (optional)
  • See the 4 Series MSO family HERE.

Limited-Time Offer
Get a FREE bandwidth upgrade* when you buy 350 MHz or higher, and our FREE Software bundle 4-PROMO-1 (which includes 4-AFG, 4-PWR-BAS, 4-SRAUTO, 4-SRCOMP, 4-EMBD, and 4-SV-BAS)
(*Bandwitch Upgrade Example: Order 350 MHz MSO44 4-BW-350 Oscilloscope and get a FREE SUP4-BW03T054 500 MHz bandwidth upgrade)

Source Measure Unit Instruments

Limited-Time Offer
Get 15% OFF when you purchase two or more of the following 2600 Series SMU instruments:

Keithley 2600 SMU Source-Measure Units
Model Channels Max Current
DC / Pulse
Max
Voltage
Measurement
Resolution
Power* Version**
2601B 1 3A / 10A 40V 100fA / 100nV 40.4 W
2602B 2 3A / 10A 40V 100fA / 100nV 40.4 W
2604B 2 3A / 10A 40V 100fA / 100nV 40.4 W Benchtop
2611B 1 1.5A / 10A 200V 100fA / 100nV 30.3 W
2612B 2 1.5A / 10A 200V 100fA / 100nV 30.3 W
2614B 2 1.5A / 10A 200V 100fA / 100nV 30.3 W Benchtop
2635B 1 1.5A / 10A 200V 0.1fA / 100nV 30.3 W
2634B 2 1.5A / 10A 200V 1fA / 100nV 30.3 W Benchtop
2636B 2 1.5A / 10A 200V 0.1fA / 100nV 30.3 W

Keithley 2400 Series Source Measure Units
Model Touchscreen Ch. Max Current Source
/Meas. Range
Max Voltage Source
/Meas. Range
Meas. Res.
(Current/Voltage)
Power
2401 No  1 1A 20V 1pA / 100nV 20 W
2450 Yes  1A 200V 10fA / 10nV 20 W
2400 No 1 1A  200V 1pA / 100nV 20 W
2410 No 1 1A 1100V 1pA / 100nV 20 W
2460 Yes 1 7A 100V 1pA / 100nV 100 W
2420 Yes 1 3A 60V 10pA / 100nV 60 W
2440 No 1 5A 40V 10pA / 100nV 50 W
2461 Yes 1 10A 100V 1pA / 100nV 1000 W
2470 Yes 1 1A 1100V 10fA / 100nV 20 W



Complete this form for a quote


Terms & Conditions:

  • Offer runs April 1, 2020 - September 30, 2020
  • Offer applies to new products sales only, including GSA. Encore, demo, or used sales do not qualify
  • Customer's purchase order must be placed and accepted between April 1, 2020 - September 30, 2020.  Open quotes with this program discount after the end date will not qualify.
  • Offer can be combined with the education discount, including CFI.
  • Offer cannot be combined with any other programs include Registration or other promotions than otherwise noted.
  • Tektronix reserves the right to change or cancel this program at any time.
