6 Series B MSO: More Bandwith. More Channels. Less Noise.

Tektronix 6 Series B Mixed-Signal Oscilloscope
Embedded designs are getting smarter. Incorporating more sensors. Using faster clocks and high-speed serial buses to move and process more data. Introducing the industry’s first 10 GHz mixed-signal oscilloscope with 4, 6 or 8 channels, designed to meet the needs of today’s most demanding applications.

The Tektronix 6 Series B mixed-signal oscilloscope combines the same great usability of previous models with significant advancements. Beautifully designed, this high-precision instrument features more bandwidth, channels and speed with less noise. You’ll also benefit from the largest (15.6” HD) capacitive pinch-zoom-swipe touch display on the market with intuitive drag and drop, object-oriented user interface.

All the features and capabilities required for advanced automotive, aerospace, defense, and semi-conductor applications:

  • More Channels: 4, 6 or 8 Flexchannel inputs
  • Leading signal fidelity with 12-bit ADCs and extremely low noise
  • 12-bit ADCs and low-noise preamps for accurate measrements
  • Powerful built-in measurements, statistics and trend plots
  • TekVPI probe interfaces support a wide range of probes
  • Application-specific measrements and automated testing

Addresses the new requirements of high-speed data movement and processing in embedded designs.  Learn more about the new Tektronix 6 Series MSO.

Model Bandwidth Channels Vert. Resolution Record Length
MSO64B 6-BW-1000 1 GHz 4 12-bits 62.5 M
MSO64B 6-BW-2500 2.5 GHz 4 12-bits 62.5 M
MSO64B 6-BW-4000 4 GHz 4 12-bits 62.5 M
MSO64B 6-BW-6000 6 GHz 4 12-bits 62.5 M
MSO64B 6-BW-8000 8 GHz 4 12-bits 62.5 M
MSO64B 6-BW-10000 10 GHz 4 12-bits 62.5 M
MSO66B 6-BW-1000 1 GHz 6 12-bits 62.5 M
MSO66B 6-BW-2500 2.5 GHz 6 12-bits 62.5 M
MSO66B 6-BW-4000 4 GHz 6 12-bits 62.5 M
MSO66B 6-BW-6000 6 GHz 6 12-bits 62.5 M
MSO66B 6-BW-8000 8 GHz 6 12-bits 62.5 M
MSO66B 6-BW-10000 10 GHz 6 12-bits 62.5 M
MSO68B 6-BW-1000 1 GHz 8 12-bits 62.5 M
MSO68B 6-BW-2500 2.5 GHz 8 12-bits 62.5 M
MSO68B 6-BW-4000 4 GHz 8 12-bits 62.5 M
MSO68B 6-BW-6000 6 GHz 8 12-bits 62.5 M
MSO68B 6-BW-8000 8 GHz 8 12-bits 62.5 M
MSO68B 6-BW-10000 10 GHz 8 12-bits 62.5 M

Tektronix 6 Series B MSO Product Fact Sheet
