Preen AFV Series Programmable Power Source

The newly upgraded AFV+ Series high-power programmable AC power source has the features, power and reliability to drive your modern application testing.

It starts with an intuitive 7” touchscreen, advanced PWM technology, and power with THD 0.5% and up to 2000kVA. The AFV+ Series has 3-phase independent adjustment to simulate advanced power line disturbance, and STEP and RAMP programmable functions to easily simulate single or continuous output changes.

All of this makes the series ideal for R&D design verification, quality assurance and production checks across home appliance, motor, medical equipment, lighting and EMC lab applications.

  • Output frequency of 45~65Hz with accuracy of ± 0.02%
  • Low total harmonic distortion
  • Wide output voltage range
  • 45~500Hz option expands the frequency

New control software provides convenient remote operation and monitoring. A standard RS-232/RS-485/RS-422 interface card and optional GPIB and Ethernet interfaces provide simple setup and programming.



Model Description
AFV-31010 10kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31015 15kVA,3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31020 20kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31030 30kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31045 45kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31060 60kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31075 75kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31100 100kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31120 120kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-31150 150kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33010 10kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33015 15kVA,3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33020 15kVA,3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33030 30kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33045 45kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33060 60kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33075 75kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33100 100kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
AFV-33120 120kVA, 3 Phase In, 3 Phase Out. 0~300Vrms, 45~500Hz Output
