20% OFF - Tek's Online Black Friday Sale!
Offer: Nov. 25, 2019 - Dec. 15, 2019




Time Domain + RF = The Perfect Bench Solution

Designing and testing devices for IoT and other connectivity applications requires solutions to address embedded design, antenna design, and RF interference to name a few. Whether you’re a Maker, or design engineer working with the latest hardware, you no longer need to hunt for the perfect Time and RF solution this Black Friday – we’ve gathered them for you.


Models:
TBS2072 70MHz up to 1 GS/s 20 Mpoints 2 Analog Channels
TBS2102 100MHz up to 1 GS/s 20 Mpoints 2 Analog Channels
TBS2074 70MHz up to 1 GS/s 20 Mpoints 4 Analog Channels
TBS2104 100MHz up to 1 GS/s 20 Mpoints 4 Analog Channels

TBS2000 Series Oscilloscopes.
See more, do more, and save money.

The TBS2000 has everything you could want in its class.
This series is perfect for fast, accurate signal measurement, and has technology capabilities typically found in higher performing scopes.

  • 70 and 100 MHz bandwidth
  • 9 inch WVGA display and 15 horizontal divisions – the most in its class
  • 32 automated measurements
  • 20 million point record length to capture long time windows
  • Courseware Library/Help Everywhere

Models:
RSA306B 9 kHz to 6.2 GHz, 40 MHz, 100 µs, 60 dBc
RSA503A 9 kHz to 3.0 GHz, 40 MHz, 15 µs, 70 dBc
RSA603A 9 kHz to 3.0 GHz, 40 MHz, 100 µs, 70 dBc

RSA306B/503/603 Spectrum Analyzers
Track RF interference in the field, in the lab, or on the bench.
Don’t waste time and resources tracking down EMI with just any solution. The RSA family of spectrum analyzers are USB powered for desktop or field measurements. They have the industry’s lowest noise, highest fidelity real-time spectrum analyzer for finding hidden signals in the field, in the lab, or on the bench.

  • At 1.6 pounds, the RSA306B is tested to be military-grade durable for field use
  • USB powered
  • With DPX Technology, see RF signals that are near invisible to a conventional spectrum analyzer
  • Up to 7.5 GHz frequency coverage, with 40 MHz bandwidth capture


MSO/DPO2000B Mixed Signal Oscilloscope
Automate serial and parallel bus analysis, fast.
The MSO/DPO2000B is the most versatile and reliable scope in its class, at an affordable price point. You get the tools you need to speed up your debugging while automating serial and parallel bus analysis quickly and accurately.

  • Up to 20 channels – 4 analog and 16 digital channels
  • Up to 200 MHz bandwidth
  • 1 GS/s sampling rate
  • Wave Inspector simplifies waveform analysis, enabling you to zoom in, and easily locate that hard to find transient
Models:
DPO2002B 70 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch.
DPO2012B 100 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch.
DPO2004B 70 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch.
MSO2002B 70 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch., 16 Digital Ch.
DPO2022B 200 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch.
DPO2014B 100 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch.,
MSO2012B 100 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch., 16 Digital Ch.
MSO2004B 70 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch., 16 Digital Ch.
DPO2024B 200 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch.
MSO2022B 200 MHz, 1 GS/s, 1 Mpoints, 2 Analog Ch., 16 Digital Ch.
MSO2014B 100 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch., 16 Digital Ch.
MSO2024B 200 MHz, 1 GS/s, 1 Mpoints, 4 Analog Ch., 16 Digital Ch.

Models
TTR503A Two ports, type-N female connectors 100 kHz - 3 GHz

TTR500 Vector Network Analyzer
Validate the performance of RF components and devices.
The TTR500 makes wireless devices possible. It’s an invaluable addition to your bench to measure magnitude and phase response of many RF and microwave components and systems. A necessary instrument in characterizing devices, and antenna matching

  • Super compact foot print, UBS powered, less than 3 pounds
  • Measure S-parameters in log magnitude, phase, SWR, impedance and admittance formats
  • Measure as much as 40 dB of return loss to characterize RF components
Terms and Conditions
  • Offer applies to Americas sales only.
  • Combinable with standard Education discount; applies for qualified Education customers.
  • This program is applied to select models of the TBS2000 Series, MSO-DPO2000 Series, RSA306B, RSA503A, RSA603A, and TTR503A, during the sales program period to end-customers.
  • Offer applies to new product sales only. Encore, demo, or used sales do not qualify.
  • The purchase order from the customers must be placed and accepted between November 25, 2019 and December 15, 2019.
  • Tektronix reserves the right to change or cancel this program at any time.
  • Program terms and conditions that apply to end customers can be found at www.tektronix.com/promotions.
