Expanded & Enhanced Data Acquisition Systems from Keysight


What could be better than the industry's best general-purpose DAQM901A 20-channel multiplexer module for free? For a limited time, you can buy a combination of a data acquisition (DAQ) mainframe (DAQ970A or DAQ973A) with the latest digitizer module (DAQM909A) and get the DAQM901A multiplexer module at no extra cost. See Promotion Conditions at the bottom of this page for how to redeem your free DAQM901A from Keysight.

See Promotion Conditions at the bottom of this page for how to redeem your free DAQM901A from Keysight or click the button below to request a quote now:

NEW: DAQ973A: DAQ system with USB, LAN and GPIB
DAQ973A adds GPIB capability to the popular DAQ970A. Both models have a built-in advanced 6 ½ digit digital multimeter (DMM) for fast and accurate measurements. The internal analog to digital converter allows measurement speeds of up to 50000 readings per second with high resolution. It comes with an intuitive LCD screen and soft keys for easy configuration and measurement displays in multiple formats: number, bar meter, trend chart, and histogram chart.

NEW: DAQM909A 4-Channel Digitizer Module
DAQM909A digitizer module has up to four simultaneously sampling input channels with differential inputs. Each channel can set sampling rates from 100 kSa/s  (frequency domain) to 800 kSa/s (time domain) with 24-bit resolution. Each channel can be independently programmed to one of four input modes, and current source settings. Ideal for electro-mechanical components design validation and characterization, power analysis, acoustic measurement and analytics, condition monitoring, and more.

The complementary DAQM901A 20 + 2 Channel Multiplexer Module is the most versatile multiplexer for general purpose scanning. It combines dense, multi-function switching with 80-channel/second scan rates to address a broad spectrum of data acquisition applications. The module comes with two- and four-wire channel configurations that can be mixed on the same module. Two additional fused inputs (22 channels total) route up to 1 A of current to the internal DMM, allowing AC and DC current measurements without the need for external shunt resistors.

PLUS, the DAQ970A family now includes these enhancements!

  • NEW: 50,000 readings/s (DAQ970A/DAQ973A with new firmware).
  • NEW: 1 million points scanning memory (DAQ970A/DAQ973A with new firmware).
  • NEW: Enhanced BenchVue DAQ (Time/Frequency Domain support) included with DAQ970A and DAQ973A.

Why should I migrate from Keysight 34970A & 34972A?
Keysight DAQ970A & DAQ973A are the next generation of data acquisition systems. The DAQ970A & DAQ973A provide higher performance and flexibility while maintaining compatibility with the 34970A and 34972A:

  • Up to 100X faster reading rates
  • Up to 55% accuracy improvements for resistance
  • Up to 75% accuracy improvements for AC voltage
  • Up to 90% accuracy improvement for AC current
  • The ability to measure very low current ranges; 1 µA DC and 100 µA AC, and higher resistance range 1000 MΩ
  • Intuitive LCD screen and soft keys for easy configuration and measurement displays in multiple formats: number, bar meter, trend chart, and histogram
  • Auto-calibration which compensates for drifts in the internal DMM; or on the DAQM907A multifunction module
  • 34972A will be discontinued on May 31, 2020.

Click the button below to speak to a member of our Team:

Promotion Conditions:

  • Promotion is valid from February 1, 2020 through September 30, 2020.
  • Customers must purchase a combination of a DAQ mainframe (DAQ970A or DAQ973A) and the latest digitizer module (DAQM909A).
  • Customer must complete all required information on the claim form to be eligible for this promotion - http://www.keysight.com/find/ExpandYorDAQCapabilitiesClaim
  • Free DAQM901A Multiplexer Module will be fulfilled directly by Keysight, NOT TestEquity.
  • New qualifying product must have been purchased from TestEquity within the promo period (1:1 – one free product per qualifying product purchased)
  • Customers can claim the free product up to 90 days after promo period ends.
  • Lease and demo orders are NOT eligible to participate in this promotion
  • Remarketed or used products are NOT eligible to receive the promotion discount
  • Keysight Technologies reserves the right to modify or discontinue this offer during the promotional period without any prior notice.
